Thinking what the above diagram is all about. Once you are done with this blog, you will know exactly what it is. Till one month ago, I was of the opinion that Dynamic Inventory is a cool way of managing your AWS infrastructure as you don’t have to track your servers you just have to apply proper tags and Ansible Dynamic Inventory magically manages the inventory for you. Having said that I was not really comfortable using dynamic inventory as it was a black box I tried going through the Python script which was very cryptic & difficult to understand. If you are of the same opinion, then this blog is worth reading as I will try to demystify how things work in Dynamic Inventory and how you can implement your own Dynamic inventory using a very simple python script.

You can refer below article if you want to implement Dynamic inventory for your AWS infrastructure.

https://aws.amazon.com/blogs/apn/getting-started-with-ansible-and-dynamic-amazon-ec2-inventory-management/

Now coming to what is dynamic inventory and how you can create one. You have to understand what Ansible accepts as an inventory file. Ansible expects a JSON in the below format. Below is the screenshot showing the bare minimum content which is required by Ansible. Ansible expects a dictionary of groups (each group having a list of group>hosts, and group variables in the group>vars dictionary), and a _meta dictionary that stores host variables for all hosts individually (inside a hostvars dictionary).

So as long as you can write a script which generates output in the above JSON format. Ansible won’t give you any trouble. So let’s start creating our own custom inventory.

I have created a python script customdynamicinventory.py which reads the data from input.csv and generates the JSON as mentioned above. For simplicity, I have kept my input.csv as simple as possible. You can find the code here:-

https://github.com/SUNIL23891YADAV/dynamicinventory.git

If you want to test it just clone the code and replace the IP, user and key details as per your environment in the input.csv file. To make sure that our python script is generating the output in standard JSON format as expected by Ansible. You can run ./customdynamicinventory.py –list
And it will generate the output in standard JSON format as shown in below screenshot.

If you want to check how the static inventory file would have looked for the above scenario. You can refer to the below screenshot. It would have served the same purpose as the above dynamic inventory

Now to make sure your custom inventory is working fine. You can run

ansible all -i customdynamicinventory.py -m ping

It will try to ping all the hosts mentioned in the CSV. Let’s check it

See it is working, that’s how easy it is.

Instead of a static CSV file, we can have a database where all the hosts and related details are getting updated dynamically. Then Ansible dynamic inventory script can use this database as an inventory source as long as it returns a JSON structure, mentioned in the first screenshot.

As a DevOps Engineer, I always love to make things simple and convenient by automating them. Automation can be done on many fronts like infrastructure, software, build and release etc.

Ansible is primarily a software configuration management tool which can also be used as an infrastructure provisioning tool.
One of the thing that I love about Ansible is its integration with different cloud providers. This integration makes things really loosely coupled, For ex:- we don’t require to manage whole information of cloud in Ansible (Like we don’t need instance metadata information for provisioning it).

Ansible Inventory

Ansible uses a term called inventory to refer to the set of systems or machines that our Ansible playbook or command work against. There are two ways to manage inventory:-

Static Inventory
Dynamic Inventory

By default, the static inventory is defined in /etc/ansible/hosts in which we provide information about the target system. In most of the cloud platform when the server gets reboot then it reassigns a new public address and again we have to update that in our static inventory, so this can’t be the lasting option.

Luckily Ansible supports the concept of dynamic inventory in which we have some python scripts and a .ini file through which we can provision machines dynamically without knowing its public or private address. Ansible Dynamic Inventory is fed by using external python scripts and .ini files provided by Ansible for cloud infrastructure platforms like Amazon, Azure, DigitalOcean, Rackspace.

In this blog, we will talk about how to configure dynamic inventory on the Azure Cloud Platform.

Ansible Dynamic Inventory on Azure

The first thing that always required to run anything is software and its dependencies. So let’s install the software and its dependencies first. First, we need the python modules of azure that we can install via pip.

$ pip install 'ansible[azure]'

After this, we need to download azure_rm.py

$ wget https://raw.githubusercontent.com/ansible/ansible/devel/contrib/inventory/azure_rm.py

Change the permission of file using chmod command.

$ chmod +x azure_rm.py

Then we have to log in to Azure account using azure-cli

$ az login
To sign in, use a web browser to open the page https://aka.ms/devicelogin and enter the code XXXXXXXXX to authenticate.

The az login command output will provide you a unique code which you have to enter in the webpage i.e.
https://aka.ms/devicelogin

As part of the best practice, we should always create an Active Directory for different services or apps to restrict privileges. Once you logged in Azure account you can create an Active Directory app for Ansible

$ az ad app create --password ThisIsTheAppPassword --display-name opstree-ansible --homepage ansible.opstree.com --identifier-uris ansible.opstree.com

Don’t forget to change your password ;). Note down the appID from the output of the above command.

Once the app is created, create a service principal to associate it with.

$ az ad sp create --id appID

Replace the appID with actual app id and copy the objectID from the output of the above command.
Now we just need the subscription id and tenant id, which we can get by a simple command

$ az account show

Note down the id and tenantID from the output of the above command.

Let’s assign a contributor role to service principal which is created above.

$ az role assignment create --assignee objectID --role contributor

Replace the objectID with the actual object id output.

All the azure side setup is done. Now we have to make some changes to your system.

Let’s start with creating an azure home directory

$ mkdir ~/.azure

In that directory, we have to create a credentials file

$ vim ~/.azure/credentials

[default]
subscription_id=id
client_id=appID
secret=ThisIsTheAppPassword
tenant=tenantID

Please replace the id, appID, password and tenantID with the above-noted things.

All set !!!! Now we can test it by below command

$ python ./azure_rm.py --list | jq

and the output should be like this:-

{
  "azure": [
    "ansibleMaster"
  ],
  "westeurope": [
    "ansibleMaster"
  ],
  "ansibleMasterNSG": [
    "ansibleMaster"
  ],
  "ansiblelab": [
    "ansibleMaster"
  ],
  "_meta": {
    "hostvars": {
      "ansibleMaster": {
        "powerstate": "running",
        "resource_group": "ansiblelab",
        "tags": {},
        "image": {
          "sku": "7.3",
          "publisher": "OpSTree",
          "version": "latest",
          "offer": "CentOS"
        },
        "public_ip_alloc_method": "Dynamic",
        "os_disk": {
          "operating_system_type": "Linux",
          "name": "osdisk_vD2UtEJhpV"
        },
        "provisioning_state": "Succeeded",
        "public_ip": "52.174.19.210",
        "public_ip_name": "masterPip",
        "private_ip": "192.168.1.4",
        "computer_name": "ansibleMaster",
        ...
      }
    }
  }
}

Now you are ready to use Ansible in Azure with dynamic inventory. Good Luck 🙂
